B2 HVA68 - 2 VLF 48 kV(RMS) 68 kV(Peak) High Voltage Test Set

B2 HVA68 - 2 VLF 48 kV(RMS) 68 kV(Peak) High Voltage Test Set

High Voltage Power Output to Weight Ratio Read More
Minimum hire period: 1 week
Hire now
Delivery and Collection from: £143.00
Get a quote
  • Description
  • Specifications
  • Delivery & Returns
This New VLF Set Has An Excellent Output Power to Weight Ratio Within A Compact Design

The combination of this unit's high voltage power output to it's weight ratio, make this instrument perfectly suited to HVA testing across sites & projects.

The HVA68-2 boasts 2 µF @ 0,1 Hz @ 44 kVrms, this increase in power, does not result in an increase in the weight of the instrument making it a great choice for on-site HVA Testing. The system is also a dry type test system with no oil filled components. This has the benefit of meaning less maintenace of the unit is required in general, and also ensures there is no limit on operating time.

  • Input Voltage - 190 – 240 V, 50/60 Hz, 3 kVA

Output Voltages
  • Sinusoidal - 48 kV rms, 68 kV peak
  • DC± 0 – 60 kV
  • Squarewave 0 - 60 kV
  • Accuracy ± 1%
  • Resolution - 0.1 kV
  • Cable testing according: CENELEC HD 620/621,IEEE 400.2-2004,IEC60502-2:2014

Additional Features
  • Pure sinusoidal output voltage (load-independent)
  • Performance: 2 µF @ 0,1 Hz @ 44 kVrms
  • Output current 80 mA max.
  • Highest test capacity of 10 μF
  • Programmable test sequences
  • Integrated 12 kV transient protection (50 Hz)
  • Dual Discharge Device (DDD®) two integrated and automatic discharge devices
  • Easily exchangeable HV cable
  • Intuitive menu operation
  • Sheath Fault Locating (in combination with Earth Fault Location)
  • Vacuum Bottle Test
  • Insulation Testing

Please Note: Due to this item's size and weight, this is a palletised delivery

Product code: INL1200
Depot: STK
  • Output voltage 48 kV
  • VLF & DC Sinusoidal VLF output voltage up to 68 kV (44 kV RMS)
  • 12kV transient protection (50 Hz)
  • PC software “B2 Control Center” with various reporting functions included
  • Weight - 57 kg
  • Please Note: Due to this item's size and weight, this is a palletised delivery
