Baur PGK 50E HV DC Test Set
Generate Negative Voltages Up to 50kV Read More
You might also need
The Baur PGK 50 HV DC test set is a portable high voltage device used for the generation of negative high voltage up to 50KV, they are designed for site testing of paper-insulated oil-impregnated cables in medium voltage networks.
The PGK 50 is well-equipped for field applications.
Features
- Voltage measurement is made directly at high voltage output
- Timer 1-30mins
- Sensitive current measurement for acquisition of smallest insulation currents (6 ranges)
- High short-circuit current
- Safety control according to VDE 0104
- Transient wave protection
- Socket for safety contact, emergency off switch, external signal lamps connection on Y/t plotter for recording the current output
- Rated output voltage 50KV<
- Rated output current 2mA at 50KV
![](https://assets.inlec.com/media/INL397.png?2023-08-16" alt="INL397)
- Well equipped for field applications
- Fully portable with carry case and strap
- Up to 50KV test capability
- Step less adjustable output voltage
- Dimensions: h.495mm w.460mm d.285mm
- Weight: 25kg
