Fluke 715 Volt/mA Calibrator

The Fluke 715 Volt/ mA Calibrator delivers outstanding performance, durability and reliability. Offered in the rugged Fluke 80 Series DMM package, the calibrator is compact, lightweight, and easy to carry

With a push button interface similar to the multifunction Fluke 740 Series Documenting Process Calibrators, the 715 is easy to use. It is EMI tolerant, dust and splash resistant, and features a removable battery door for quick battery changes.

Features

• Measure loop current (0-20 mA, 4-20 mA) signals with very high accuracy of 0.015% and 1 mA resolution
• Measure voltage output process signals from PLCs, transmitters
• Source or simulate 24 mA loop current
• Source voltage to 100 mV or 10V
• 24V loop supply with simultaneous current measurement
• Enhanced voltage and current measure and source accuracy
• Improved battery life
• 250 ohm HART resistor with loop power
• Holster features test lead storage
• Compatible with toolpack magnetic hanging system
• Step and linear ramp output function
• Configurable zero and span settings

• Enhanced voltage and current measure and source accuracy
• Measure voltage output process signals from PLCs, transmitters
• 250 ohm HART resistor with loop power
• Step and linear ramp output function
• Dimensions: h.187mm w.87mm d.32mm
• Weight: 330g

Datasheet
