Hi-Force Air Driven Hydrostatic Pump AHP107

Hire Hi-Force's AHP Range Including the AHP107

---

AHP 107 Specifications

Max Output Pressure (bar) At Airline Input Pressure

• 10psi/0.69 bar = 62
• 50psi/3.45 bar = 373
• 100psi/6.9 bar = 738

Approximate rate of discharge (litres/min) at air input pressure 100 psi (7 bar)

• 0psi/0 bar = 1.97
• 500psi/35bar = 1.5
• 1000psi/69bar = 1.28
• 1500psi/104bar = 1.25
• 2000psi/138bar = 1.21
• 2500psi/173bar = 1.18
• 3000psi/207bar = 1.16
• 4000psi/276bar = 1.02
• 5000psi/345bar = 0.95
• 7500psi/517bar = 0.76
• 10000psi/690bar = 0.44

Additional Specifications Include:

• Fluid volume displacement per stroke (cm3) = 4
• Outlet port thread = 1/2"NPT
• Infinitely variable output pressure and fluid displacement speed
• Integral inlet air filtration and lubrication unit with air pressure gauge
• Airline regulator for easy setting of input air and output hydraulic pressure
• Maximum air consumption of 0.79 m3 (28 scfm) per minute at 7 bar
• Smooth and easily operated hydraulic pressure hold and release valve
• Fitted with input air pump start/stop valve for easy and fast pressure shut-off
• Robust powder-coated stainless steel protective framework
• Lightweight plastic, 7.5 litres capacity, fluid reservoir
• Optional stainless steel reservoir, stroke counter system and pressure isolation valve available on request

• Weight - 20Kg
• 1/2"NPT outlet port thread

Datasheet
