Inno Instrument View 8 Pro Premium Core Alignment Splicer

Inno Instrument View 8 Pro Premium Core Alignment Splicer

Fusion Splicer with In-Built Cloud Reporting Read More
£POA
**Add to order, and we will contact you to confirm which modules you need
Quantity
Hire now
Delivery and Collection from: £44.00
Get a quote
  • Description
  • Specifications
  • Delivery & Returns

Premium Core Alignment Splicer with Mobile Data Connectivity, Asset and Work Management Platform

High quality fusion splicer designed to make splicing as efficient as possible with a quick-mode and six-second splice time and nine second heating time.



Additional Manufacturer Specifications

  • RESULT STORAGE 10,000 Splice Data 10,000 Splice Image
  • CLEAVED LENGTH 5 ~ 16mm
  • CLADDING DIAMETER 80~150um
  • COATING DIAMETER 100~3000um
  • SPLICING MODE Max 128 modes
  • HEATING MODE Max 32 modes
  • TYPICAL SPLICE LOSS SM: 0.01dB
  • MM: 0.01dB
  • DS: 0.03dB
  • NZDS: 0.03dB
  • G.657: 0.01dB
  • RETURN LOSS >> 60dB
  • ESTIMATED SPLICE LOSS Available upon request.
  • HEATING SLEEVE LENGTH 20 ~ 60mm
  • TENSION TEST 1.96 ~ 2.25N
  • OPERATING CONDITION Altitude: 0 ~ 5,000m above sea level, 0.95% relative humidity,
  • -10 ~ 50℃, Max Wind 15m/s
  • STORAGE CONDITION 0 ~ 95% relative humidity, -40 ~ 80℃
  • POWER SUPPLY AC Input 100 – 240V,
  • DC Input 9 – 14V
  • BATTERY CAPACITY LBT-30, Typical usage: 355 cycles /
  • Power save usage: 450 cycles
  • ELECTRODE LIFE 5500 arcs discharges

Product code: INL1387
Depot: RDC
  • 6 Second Splicing Time in Quick Mode
  • 8 Second Splicing Time in Auto Mode
  • Weight - 2.12KG (without battery) 2.78KG (with battery)
  • 5” Color LCD Touch Screen
