Megger DLRO10 Digital Low Resistance Ohmmeter

The DLRO10 Digital Low Resistance Ohmmeter Is A Lightweight & Robust Instrument Which Is Equally At Home In The Field Or In The Laboratory

Typical applications for the DLRO10 are:

• Switch and contact breaker resistance
• Bushbar and cable joints
• Aircraft frame bonds and static control circuits
• Integrity of welded joints
• Intercel connections on battery systems up to 600V peak
• Quality control of resistive components
• Transformer and motor winding resistance
• Rail and pipe bonds
• Metal alloys, welds and fuse resistance
• Graphite electrodes and other composites
• Wire and cable resistance
• Transmitter aerial and lighting conductor bonding

Features

• Automatically applies forward and reverse currents which cancel out any outstanding voltages across the sample under test
• Checks for undue noise during measurement, reducing the possibility of recording the incorrect results
• Automatically detects continuity in P and C circuits, preventing erroneously high reading to be taken due to high resistance contact

Technical Specifications

• Test method: single cycle reversing dc ratiometric measurement - average result display
• Test current: Accuracy ±10% : Stability
• Battery capacity : 7Ah NiMH rechargeable
• Life : Typically 1000 x 10A tests before recharge
• Charging rate: 2.5 hours to 90% capacity, 4 hours to full charge

• Four terminal resistance method shows the true resistance of the item under test
• Strong, lightweight and durable. Ideal for confined areas
• Large, easy-to-read back-lit display
• Full flexibility by allowing the user to set high and low limits
• Dimensions: h.220mm w.237mm d.100mm,
• Weight: 2.6kg
