Thermtest TLS-100 Thermal Conductivity Meter

The TLS-100 is a portable meter used to measure thermal conductivity and thermal resistivity of a variety of samples, including soil, rocks, concrete, and polymers.

Tests can be performed with the push of a button and results are displayed instantly.

• The Transient Line Source (TLS) meter follows ASTM D5334-14. The sensor needle consists of a thin heating wire and temperature sensor sealed in a 100 or 50 mm steel tube. The sensor is completely inserted into the sample to be tested. Heat is delivered to the sample using a constant current source (q) and the temperature rise is recorded over a defined period of time.
• The slope (a) from the plot of temperature rise versus the logarithm of time is used in the calculation of thermal conductivity (k). The higher the thermal conductivity of a sample, the lower the slope. For samples of low thermal conductivity, the slope will be higher.

THERMAL CONDUCTIVITY OF CERAMICS
Discovering the heat resistant and insulative nature of ceramics, through thermal conductivity testing.

THERMAL CONDUCTIVITY OF SNOW
A look into the effect of compaction on the thermal conductivity of snow.

THERMAL CONDUCTIVITY OF SOIL
Evaluating the thermal conductivity of varying soil moisture for applications in construction and agriculture fields.

• Measure the thermal conductivity of a variety of material
• Discover the heat-resistant and insulative nature of ceramics, through thermal conductivity testing
• A look into the effect of compaction on the thermal conductivity of snow.
• thermal conductivity of varying soil moisture for applications in construction and agriculture fields.

Datasheet
