Trolex XD-One Personal Dust Monitor

The Trolex XD One personal dust monitor is designed to provide detailed, accurate, real-time data on airborne particulates so that users can take appropriate actions to stay safe and ensure personnel are fully protected from particulate-related health hazards.

The XD One allows users to specifically monitor respirable particulate matter (PM) to indicate and warn of personal exposure in working and operating environments. The device can be configured to measure and warn users based on selectable particulate matter sizes (PM1.0, PM2.5, PM4.25 and PM10) and
report on all environmental Total Suspended Particulates (TSP).

The XD One uses an innovative light scattering photometer that combines adaptive flowrate with advanced sensing technology to ensure a high level of measurement accuracy. The size of each particle is instantaneously measured and classified at up to 10,000 samples a second to allow detailed real-time
reporting in high dust environments.

Precise data is collected for all measurable particulates, enabling detailed concentration profiling and analysis using the Trolex BreatheLITE application software. As the XD One records data on all particulates between 0.35μm and 40μm, users can easily access and view detailed information about a
wide range of particulate sizes.

Measurement information is displayed on the device in the form of custom Short Term Exposure Limit (STEL) or Long Term Exposure Limit / Time Weighted Average (TWA) audiovisual alarms, or directly connected to the Trolex BreatheLITE application for Live particulate readings.

• It weighs only 450g and has a 16+ hour battery life.
• Low-end sensor resolution, measuring down to 0.35µm with 99% capture
• Custom particle density for increased characterisation
• Operational stability in varying atmospheric and environmental conditions
• Custom Logging Intervals from 10s – 60s
• On-device audio/visual alarms
• Custom alarm set points
• Custom STEL and TWA period alarm thresholds
• On-device self-check routine
• Battery operated, rechargeable (16hrs+)
• On-device data logging
• Live data readout via BreatheLITE application
• Data analytics functions via the BreatheLITE application
• Range of personal, industrial and cabin mounting options
• Low maintenance

• Personal, portable, mountable and moveable
• Designed to provide early warning of personal exposure to airborne particulates
• On device early warning alerts for increased particulate levels
• PM1, 2.5, 4.25 and 10 and TSP measurement ranges
• 0.35µm - 40µm particle sizing range

Datasheet
