Chauvin Arnoux CA 8335 Qualistar Plus Power Analyser

This item has now been superseded by the CA8336 - please click here

The CA8335 Qualistar Plus Power Analyzer is a three phase power analyser and is recognized for its simplicity and performance. The instrument has been designed with engineers in mind. The small size and weight makes the kit ideal for field use, it is also truly portable as it is battery powered.

• The four voltage and current wave forms are displayed in real time, the RMS voltage and currents per half period are shown also.
• Automatically recognizes different types of current sensors and monitors electrical network
• Integration of all the DC components
• Measurement, calculation and display of the harmonics up to the 50th order, along with the phase information
• Calculation of Total Harmonic Distortion (THD), flicker, unbalance in current and voltage and K-Factor
• Capture of transients per sample (1/256th of a period) and captures 300 transients
• Display of phasor diagram
• Measures VA, W, var power values (total and per phase), VAh, Wh and varh energy values (total and per phase)
• Calculations of the displacement power factor (DPF) and the power factor (PF)
• Back-up and recording of screenshots (image and data)
• Has an intuitive control scheme, full time connectivity in real time with a PC and data recovery

• Ideal for technicians and electricians
• Real-time display of wave forms (4 voltages and 4 currents)
• Can be used on single and three phase systems
• Battery powered making it truly portable
• Dimensions: h.200mm w.250mm d.67mm,
• Weight: 1.95kg

Datasheet
