Chauvin Arnoux CA 8345 Class A Power Analyser

Class A Power Quality Analyser with A Range Of User-Friendly Features Designed For Energy Surveys, Auditing & Routine Electrical Maintenence Tasks.

Now updated with Better Harmonic Measurement and Improved Inrush Mode

The latest firmware update to this product now means the unit offers the following features:

• Better Harmonic Measurement: The harmonic measurement capabilities have been improved to encompass up to the 127th order, along with inter-harmonics up to the 126th order. This surpasses the requirements outlined by industry standards such as the UK Energy Network Association Engineering Recommendation G5-5 and IEEE 519-2022 Standard for Harmonic Control in Electric Power Systems, which mandate harmonic measurement up to the 100th order.
• Improved Inrush Mode: Experience the added convenience of an automatic 100ms pre-trigger in the Inrush mode, enhancing functionality on your CA8345. Now, your device seamlessly displays the pre-trigger waveform preceding the inrush waveform, streamlining analysis. With CA 8345, you can view 100ms of the pre-trigger waveform, followed by the inrush waveform, with the cursor intuitively set at 0s, marking the initial zero crossing of the triggered period.

Features

• Monitor and record trends which show the variation of your chosen parameters at 200ms intervals
• Set custom alarms for your selected parameters
• Capture transients

Common Applications

• Energy Surveys
• Energy Efficiency Monitoring and Auditing
• Electrical Maintenance
• Facility Management of electrical infrastructure

Connectivity

All your testing data can be saved onto an SD Card or USB drive and copied to your computer. The device can be linked with android and ios devices

• Software that records and monitors in real time
• USB Connector
• USB Drive Connector
• SD Card Reader
• FJ45 Connector
• USB 2.0
• Ethernet & Wifi

• IEC 61000-4-30
• EN 50160
• IEC 61000-4-7
• IEC 61000-4-15

• Better Harmonic Measurement with 127th Order harmonic measurement
• Improved Inrush Mode

Datasheet

User Guide
