Fluke 1777 Three Phase Power Quality Analyser Class A

Class A Power Quality Analyser

Applications

• Troubleshooting power quality issues
• Monitoring and recording power sources
• Conducting system checks
• Power Quality Analysis
• Energy surveys and load testing
• Harmonic surveys
• Nuisance circuit breaker tripping
• Electric utility power quality surveys
• Discovery of equipment failures caused by 8kV microsecond transients

Product Features

• The instrument automatically logs power and power quality parameters
• Simple data downloads using a USB memory stick, WiFi, LTE, wired Ethernet, or USB cable
• One-touch reporting creates standardized reports conforming to standards like EN 50160, IEEE 519, GOST 33073 IEC 61000-2-2, or export data in PQDIF or NeQual compatible format or CSV for use with third-party software
• Large easy to read screen provides at-a-glance power quality health for faster troubleshooting
• Easily view V/A/Hz, power, dips, swells, and harmonics data
• Capture high-speed transients up to 8 kV
• Power directly from measurement circuit without a line cord
• The Ability to Discover Equipment Failures Caused By 8kV Nanosecond Transients

Connectivity

• Ethernet - 1Gbit/s
• USB type A
• USB-C
• Wifi
• 4G

• The Latest, Feature-Packed Fluke Power Analyser With High Speed Sampling Rate of 20MS/s
• Automatic measurement capture
• High-speed voltage transient capture
• Compliant to the latest international standards
• View, Download and Share Data with Fluke Energy Analyze Plus software

Datasheet

User Guide
