Hydrajaws M2000 with Safety Lifeline Cable Tester Kit

The Hydrajaws M2000 Safety Lifeline Cable Tester Kit 2 offers a comprehensive solution for Anchor Testing, enabling engineers to validate the installation of anchors, eyebolts, and swaged components of new or existing engineered lifeline systems to ensure compliance with BS 8539, BS 7883:2019 and BS EN 795:2012 up to a maximum tensile load of 25kN (5620lbf)

Comes with all the accessories such as Bolt tester adaptor with M12 locking adaptor and Turning Handle with 22mm integrated nut (for use in confined spaces) along with a digital rechargeable gauge that is equipped with advanced-data logging through FREE-to-use Hydrajaws Verify PRO App via Bluetooth® for real-time monitoring and tracking of pull testing results up to a 10m range.

• Can be used to test the holding power of anchors in construction materials to establish safe working loads or to validate the correct installation of existing fixings.
• Hydrajaws M2000 Combined with Safety Lifeline Cable Tester
• The tester clamps directly to the 8mm wire rope and will test all the swaged components during installation and for annual inspections under BS 7883:2019 safety standards.
• You can view the Verify App Datasheet here

Kit includes the following adaptors:

• 8mm Barrel clamp
• 12mm Fork adaptor
• 20mm Clevis
• 22mm A/F ratchet spanner
• M12 Coupling adaptor
• M16 and M20 Long threaded stud adaptor
• Bolt test adaptor
• Knurled adaptor 8mm
• Wall tie spacer plate

• Accessories such as Bolt tester adaptor with M12 locking adaptor and Turning Handle with 22mm integrated nut (for use in confined spaces)
• Maximum tensile load of 25kN (5620lbf)
• Dual-scale (kN & lbf) rechargeable digital gauge gives an accurate and clear display of the readings
• Advanced-data logging with free-to-use Hydrajaws Verify PRO App via Bluetooth® up to 10m range
