The DLRO10 Digital Microhmeter is a Lightweight Robust Instrument Which Is Equally At Home In The Field or in the Laboratory.
Typical applications for the DLRO10 are:
- Switch and contact breaker resistance
- Bushbar and cable joints
- Aircraft frame bonds and static control circuits
- Integrity of welded joints
- Intercel connections on battery systems up to 600V peak
- Quality control of resistive components
- Transformer and motor winding resistance
- Rail and pipe bonds
- Metal alloys, welds and fuse resistance
- Graphite electrodes and other composites
- Wire and cable resistance
- Transmitter aerial and lighting conductor bonding
- Four terminal resistance method shows the true resistance of the item under test
- Automatically applies forward and reverse currents which cancel out any out standing voltages across the sample under test
- Checks for undue noise during measurement, reducing the possibility of recording the incorrect results
- Automatically detects continuity in P and C circuits, preventing erroneously high reading to be taken due to high resistance contact
- Alpha-numeric keypad for entering test notes
- User selectable high and low limits
- Printer output and memory
- Test method: single cycle reversing dc ratiometric measurement - average result display
- Test current: Accuracy ±10% : Stability
- Battery capacity : 7Ah NiMH rechargeable
- Life : Typically 1000 x 10A tests before recharge
- Charging rate: 2.5 hours to 90% capacity, 4 hours to full charge
- Strong, lightweight and durable. Ideal for confined areas
- Large, easy-to-read backlit display
- Full flexibility by allowing the user to set high and low limits
- Printer output and memory
- Dimensions: h.220mm w.237mm d.100mm,
- Weight: 2.6kg
