Omicron CMC356 Relay Test Set with Advanced Protection Software
Universal Tool for Substation Commissioning Read More
You might also need
The 356 is Extremely Versatile and Used Extensively By Commissioning Engineers Worldwide
It performs wiring and plausibility checks of current transformers by using a primary injection of high currents generated from the test sets. It is used to test all generations and types of protective relays including high-burden electro-mechanical relays with high power demands.
Protective Relay Testing
- Static Relays
- Numerical Relays
- High-burden electromechanical relays
- IEC 61850 IEDs -GOOSE and sampled
- End-to-end testing with GPS or IRIG-B
- Busbar protection
- Relay panels
- G59 Testing
Power Systems Simulator
- Transient fault, CB, Rogowski coil and CT simulations
- Compensated network
- Transient playback (COMTRADE, PL4 (EMTP), ...
For further technical details refer to the downloadable datasheet and user manual
![](https://assets.inlec.com/media/INL573.png?2023-09-05" alt="INL573)
- Six current outputs: 6 x 32A or 3 x 64A or 1 x 128A
- Four voltage outputs: 4 x 300V or 1 x 600V
- High accuracy for testing static and numerical relays of all types.
- IMP NOTE: This unit has been upgraded to include the Advanced Protection Software V2 supplied pre-loaded on a laptop PC see detailed description below.
- Dimensions: 450 X 145 X 390mm
Datasheet
