Omicron CP TD12

Omicron CP TD12

Module from Omicron Designed For Capacitance & Power/Dissipation Factor (tan delta) Measurements Read More
Minimum hire period: 1 week
Hire now
Delivery and Collection from: £143.00
Get a quote

You might also need

  • Description
  • Specifications
  • Delivery & Returns

The CP TD12 Is Designed To Work Alongside the Omicron CPC100 & Omicron Testrano 600 - Creating A Kit Designed For Power Dissipation Factor & Capacitance Measurements

The Omicron CP TD12 has a HV source, reference capacitor and in-built measurement electronics. The unit itself can generate output voltages up to 12kV,15kV alongside currents up to 300mA. The quality design of the unit means you are guaranteed to reach the same level of precision across different environments, the same level of accuracy that you would expect to find when using the unit in the laboratory or controlled conditions.

Product Features

  • Variable Frequency - 15Hz To 400Hz Frequency Sweep -  Enables you to increase the sensitivity of the test
  • Designed for use alongside the Omicron CPC100 or Omicron Testrano 600
  • Portable - The product is relatively lightweight which means it's easy to use on-site, transportation isn't an issue
  • Precise - As mentioned above, the unit excels at noise suppression, this increases the livelihood of gaining a result which is reliable - even in challenging conditions.

Product code: INL1093
Depot: STK
  • All-In-One Test Set
  • Wider frequency range for more sensitivity (15 Hz – 400 Hz)
  • Testing at variable frequencies for better condition diagnosis
  • Excellent suppression of mains frequency interference fields
  • High-voltage source for partial discharge measurements up to 15 kV
  • Portable component and simple to transport
  • Weight - 24Kgs (Instrument) Weight 56Kg (Shipping weight)
