Omicron CPC 100 Multifunctional Primary Test System + Omicron CP TD12 Kit

This Kit Combines The Functionality Of The CPC100 With The Addition Of The CP TD12 Which Provides The Ability to Test Dissipation, Power Factor & Capacitance Measurements

The CP TD12/15 includes a high-voltage source 12 kV/15 kV, 300 mA) a reference capacitor and measurement electronics. It achieves laboratory precision even in environments with strong interference.

CPC100 & CP12 Product Specifications

Omicron CPC100

• Weight: 29 Kg;
• Dimensions: 468 x 394 x 233 mm;
• Capacity: 800 A (or 2000 A with current booster);
• Frequency range: 15 Hz to 400 Hz;

  The Omicron CPC 100 Is A Lightweight Testing Device Capable Of Performing Most Tests Required On A Substation.

The CPC 100 is able to perform:

• Current transformer testing
• Voltage transformer testing
• Power transformer diagnosis
• Power lines testing
• High-voltage (HV) cables
• Grounding systems testing
• Rotating machines testing
• GIS systems testing
• Switchgear and circuit breakers
• IEC 61850 installations and Protection relay testing.

Test Results

• Test results can be easily stored on the internal memory and retrieved into a PC using the Ethernet cable connection.
• Alternatively storing tests on the USB memory card provided and retrieving them to the laptop provided is also possible. To reduce set up times on the substation, the device software allows technicians to set up tests off-site on a PC and later retrieve them to be performed on-site.
• The tests are automatically saved to optimise the time taken saving data manually.

Omicron CP TD 12

• The CP TD12 includes a high-voltage source reference capacitor and measurement electronics
• Is capable of generating output voltages up to 12kV
• Currents up to 300 mA
• Achieves 'laboratory precision even in environments with strong interferences'

Applications Include

• Power transformers
• Rotating machines
• Current transformers
• Voltage transformers
• High-voltage (HV) cables
• Gas-insulated switchgear (GIS) systems

• This Kit Combines The Omicron CPC100 & CP TD12
• The Addition of the CP TD12 for Dissipation, Power Factor & Capacitance Measurements
•


Datasheet
