T and R Test Equipment T&R ART3V Relay Test Set

T and R Test Equipment T&R ART3V Relay Test Set

Adaptable Relay Test Set With New Features Read More
£350.00
Minimum hire period: 1 week
Quantity
Hire now
Delivery and Collection from: £30.00
Get a quote
  • Description
  • Specifications
  • Delivery & Returns

G59 Testing With A Host Of New Features Including Upgraded Accuracy & Stability, Enhanced Display and Improved Connectivity

The ART3V Relay Test System is ideally suited for testing G59/G99 protection, including loss of mains protection.  Vector surge and df/dt (ROCOF) relays can be simply tested and timed, as well as other protection requiring one to three voltages, including:

  • Under and over frequency relays
  • Under and over voltage relays
  • Synchronising relays
  • df/dt & ROCOF relays
  • Vector surge relays
  • Transducers

In conjunction with the ART3C or a current source (such as the 200ADM-P), the ART3V can be used to test protection circuits, including:

  • Directional relays
  • Distance protection
  • Phase angle relays
  • Power relays
  • Power transducers

Output

The output of the ART3V has 4mm safety sockets for phases A, B, C and neutral.  The neutral connection may be omitted for a delta connection. The neutrals can be linked for a star connection using the provided accessory.The timing system on the ART3V is flexible and  transparent with different modes of operation.

USB Data

  • The ART3V can be connected to a USB keyboard for adding comments to tests.  Each test is stored to a USB memory key with each comment. The data is stored in a *.CSV format allowing it to be opened in all types of desktop PC spreadsheet software.


Modes of Operation

Output Adjust

  • This mode allows full control of frequency, voltage and phase.

Phase Lock Mode

  • The frequency and phase of the output can be controlled by an external reference in phase lock mode.  The reference may  be the mains supply to the ART3V, an external voltage, current.  This mode allows testing of directional and distance protection in conjunction with an external current source.

Fault Config Mode

  • Fault Config mode allows extra flexibility in testing complex timed events or several sets of values that must be applied to a relay in turn.
Product code: INL1087
  • Ideally suited to testing G59 schemes
  • 0-450V P-N output voltage
  • 20VA/phase maximum output
  • Variable Frequency 30-999.9Hz
  • Phase shift ±180.0°
  • Weight 8.9 kg
