B2 HVA 120 Compact & Universal VLF High Voltage Test Set

Compact, Portable And Powerful Engineered for Reliable and Efficient Testing of HV and Transmission Cable Networks. Packed with advanced features yet still portable, excelling in both site installations and diagnostic applications

Tan Delta and Partial Discharge Diagnostics

• HVA120 can be extended to a complete cable diagnostic system at any time.

Compact And Portable

• HVA series have been designed for maximum portability and on-site use. This makes them widely applicable for in-field use.

Dry System SYSTEM

• HVA test sets are constructed with nonarcing contacts which means no oil changes are requiredl. This eliminates the routine servicing and makes the test sets almost maintenance-free.

Product Features

• Output voltage max. 120 kVpeak, 85 kVrms
• Output load 0.5 μF @ 0.1 Hz @ 85 kVrms or 5.0 μF @ 0.01 Hz @ 85 kVrms
• VLF • DC • Jacket/Sheath Test • Sheath Fault Location mode1
• Unlimited operating time • Fault conditioning •
• DDD® Dual Discharge Device (internal) • USB Data Transfer

• Output voltage max. 120 kVpeak, 85 kVrms
• Output load 0.5 μF @ 0.1 Hz @ 85 kVrms or 5.0 μF @ 0.01 Hz @ 85 kVrms
• VLF • DC • Jacket/Sheath Test • Sheath Fault Location mode1
• Unlimited operating time • Fault conditioning •
• DDD® Dual Discharge Device (internal) • USB Data Transfer

Datasheet

User Guide
