High Voltage ALT 120D KV HV Test Set

For Testing High Voltage Aerial Lift Booms and Buckets
None
High Voltage ALT 120D KV HV Test Set
High Voltage ALT 120D KV HV Test Set
High Voltage ALT 120D KV HV Test Set
In stock
£525.00
INL816
Estimated shipping from £100.00
Next day delivery Price match Unlimited support
  • ALT – 120/60D (F)CC
  • Input: 230v, 50/60 Hz, 15A
  • Output: 0-120kVac / 0-60kVac, 3.6KVA Resistive Load
  • Up to 7.2KVA capacitive load (1.3nF, 120kV or 5.3nF, 60kV, 60Hz)
  • Weight: CONTROL – 46lbs (21kg)
  • HV TANK – 160lbs (73kg)
  • Hand truck – 65lbs (29.5kg)
Inlec accepts all major debit and credit cards

Details

The High Voltage ALT 120 KV AC hipot test set provides continuously adjustable output voltages for the testing of high voltage aerial lift booms and buckets.

Features:

  • 3.6 KVA input power, primary compensation for capacitive load
  • Continuously adjustable output voltage
  • Fixed overload, factory set to 120% of variable transformer rated output current
  • Zero Start and External Interlock provision
  • Secondary connected single range LED digital voltmeter, scaled 0-60.0kV for 60kV tap, 0-
  • 120.0kV for 120.0kV top toroid.
  • Full 7.2KVA, 60kV tap for Bucket Liner Testing
  • Dual range output current metering 0-1999µA LOW range , 0-120mA HIGH range
  • Secondary Capacitive Cancel circuit
  • ALT – 120/60D (F)CC
  • Input: 230v, 50/60 Hz, 15A
  • Output: 0-120kVac / 0-60kVac, 3.6KVA Resistive Load
  • Up to 7.2KVA capacitive load (1.3nF, 120kV or 5.3nF, 60kV, 60Hz)
  • Weight: CONTROL – 46lbs (21kg)
  • HV TANK – 160lbs (73kg)
  • Hand truck – 65lbs (29.5kg)
