High Voltage Inc. PFT-652CMF 65 kV AC Test Set

Portable 65kV AC Test Set - Great Power to Weight Ratio
new
High Voltage Inc. PFT-652CMF 65 kV AC Test Set
High Voltage Inc. PFT-652CMF 65 kV AC Test Set
In stock
£345.00
INL1000
Estimated shipping from £100.00
Next day delivery Price match Unlimited support
  • Input 120 V, 50/60 Hz, 16 amps or 230 V, 50/60 Hz, 8 amps
  • Output 0 - 65 kVac @ 30 mAac
  • Output leads: 2 Black Test Leads for Grounding, 1 Red Test Lead for HV Output (not insulated for HV), 1 RG/58U Coax for Guarded return, 1 Interconnect Cable from Controls to HV Tank
  • Dimensions - Control Case (44 x 28 x 28 cms), HV Tank (31 x 33 x 35 cms)
  • Portable - Controls 21KG, HV Tank 23kg
Inlec accepts all major debit and credit cards

Details

This PFT-652 CMF AC Test Set has been designed with portability in mind, the unit is much smaller and lighter than other 65kV AC test sets and offers many advantages for testing in the field.

The AC portable field use hipot provides continuously adjustable A C voltage typically used to provide a go/no-go or a pass/fail AC over-voltage withstand test on high voltage apparatus.

Suitable for testing switchgear, circuit breakers, reclosures, vacuum bottles, hot sticks, motor windings, bus duct, and any other equipment requiring an AC voltage proof test.

The 65kV PFT 625CMF offers a truly field portable, affordable and easy to use solution to dielectric testing.

  • Input 120 V, 50/60 Hz, 16 amps or 230 V, 50/60 Hz, 8 amps
  • Output 0 - 65 kVac @ 30 mAac
  • Output leads: 2 Black Test Leads for Grounding, 1 Red Test Lead for HV Output (not insulated for HV), 1 RG/58U Coax for Guarded return, 1 Interconnect Cable from Controls to HV Tank
  • Dimensions - Control Case (44 x 28 x 28 cms), HV Tank (31 x 33 x 35 cms)
  • Portable - Controls 21KG, HV Tank 23kg
