High Voltage PFT-302CE AC Hipot 30 kV Test Set
Continuously Adjustable AC Output Voltage Read More
You might also need
The PFT-302CE AC Dielectric Test Set, Provides Continuously Adjustable AC Output Voltage Used to Provide a Pass/Fail AC Voltage Withstand Test on high voltage apparatus
- Continuously adjustable output voltage
- Key-operated main power switch
- Secondary connected single range 3.5 digit
- Digital voltmeter
- Single range 3.5-digit digital current meter
- Guard/ground circuit for accurate leakage current measurement
- Transit-protected, glass-faced meters to prevent damage in transit
- Adjustable overload from 10 to 110% of rated output current
- Zero start safety interlock
- External interlock provisions
Can Be Used In
- Switch-Gear Circuit Breakers
- Re-Closures
- Vacuum Bottles
- Hot Sticks
- Rubber Products
- Motor Windings
- Bus Duct
![](https://assets.inlec.com/media/INL852.png?2026-05-26" alt="INL852)
- Input: 230 V, 15 amps, 50/60 Hz, single phase
- Output: 0 – 30 kVac, up to 67 mAac depending on load, sinusoidal
- Output cable: 20 ft/6 m EPR shielded cable with battery clamp termination
- Duty rating: 2 kVA, one hour ON - one hour OFF, 1 kVA continuous
- Volt Meter: 3.5 digit LED scaled 0 – 30.0 kVac (rms) +/- 1% accuracy
- Current Meter: 3.5 digit LED scaled 0 – 67.0 Milliamperes (rms) +/- 1% acc.
- Size/Weight: 23”w x 11.5”d x 15.5”h, 77 lbs. 585 x 293 x 395 mm, 35 kg
