Megger MIT525 5KV Diagnostic Insulation Resistance Tester

The MIT525 Was Designed To Assist You With The Testing & Maintenance Of High Voltage Electrical Equipment

The case is incredibly rugged and easy to carry, being made of tough polypropylene and achieving an ingress protection rating of IP65. In addition, the model number is marked on both the top and side of the case for ease of identification in stores or vehicles.As well as measuring insulation resistance to 15 TΩ, the MIT525 also offers various diagnostic tests such as Polarisation index, Dielectric Absorption Ratio, Step Voltage, Dielectric discharge and additional ramp test.

• The instrument has a large easy to read back-lit LCD display making it equally suitable for use in unlit environments. Information displayed includes resistance, voltage, leakage current, capacitance, battery status and time constant. In addition, the elapsed time of the test is displayed constantly removing the need for separate timer.

Features Include:

• CATIV 600 V
• Testing up to 5 kV
• Mains or battery powered
• Digital/analogue backlit display
• Variable test voltage from 50 to 5000 V
• Automatic IR, PI, DAR, SV, DD tests and Ramp test
• Measures to 15 TΩ;
• RS232 and USB download of results

• CAT IV 600 V
• Both digital and analogue display;
• Variable test voltage from 50 to 5000 V
• Automatic IR, PI, DAR, SV, DD tests and Ramp test;
• Dimensions: h.305mm w.360mm d.194mm
• Weight: 7.1kg

Datasheet
