Megger MIT515/2 5KV Insulation Resistance Tester

The Megger MIT 515/2 5KV Insulation Tester Is The latest In Megger's Range Of Insulation Resistance Testers

• Take measurements when connected to a mains with a dead battery with rapid charge capability
• Smaller and lighter than previous models, with an excellent new display
• The MIT515 5KV offers several saved functions, including five preset voltage ranges and five pre-configured diagnostic tests
• Also features extensive health and safety precautions, double insulation, and a safety rating to CAT IV 600 V

Suitable For

• Insulation Testing
• Resistance Measurement
• IR Tests
• Generating Reports and Data Export Features

Applications

• Cables
• Transformers
• Motors/generators
• Circuit breakers and bushings

• Measures up to 10TΩ
• Selectable test voltage from 250 V to 5000 V
• IR, IR(t), PI, DAR and DD test
• Noise filter - rejects up to 3 mA noise
• CATIV 600 V safety rating
• Dimensions: h.315mm w.285mm d.181mm
• Weight: 4.5kg

Datasheet

User Guide
