Baur Shirla Cable Sheath Fault Locator with SebaKMT ESG NT

Baur Shirla Cable Sheath Fault Locator with SebaKMT ESG NT

Supplied With KMF1 Pinpointer Read More
€765.00
Minimum hire period: 1 week
Quantity
Hire now
Delivery and Collection from: €66.00
Get a quote
  • Description
  • Specifications
  • Delivery & Returns

The All-In-One, Fully Automatic Cable Sheath Testing And Fault Location System.


The Shirla is a unique device for cable and cable sheath testing, fault pre-location and sheath fault pinpointing according to the step voltage method.

The device utilizes a special measuring bridge to perform measurements according to the Murray and Glaser methods. With it's integrated high voltage DC source, the Shirla can pre-locate both low and high resistive cable faults.

  • The measuring principle enables the pre-location of cable sheath faults and earth faults on un-shielded cables.
  • Shirla analyses the data automatically and the results are displayed digitally.

For cable fault pinpointing according to the step voltage method, Shirla applies a defined DC pulse pattern and the step voltage can be picked up by using the KMF1 or UL receiver set.


This Set Comes supplied with KMF1 pinpointer which has a seperate Datasheet which you can view and download here


Additional Features:
  • Cable sheath fault Pin Pointing
  • Integrated discharge unit
  • Step-less voltage adjustment
  • Automatic reporting function
  • Mains and battery operated
  • Menu control via one-button operation
  • Timer function for testing and switch-on delay time

Product code: INL1565
Depot: STK
  • Cable and cable sheath testing up to 10kV
  • Resistance measurement
  • Cable and cable sheath fault pre -location with high precision measuring bridge
  • Definable cable sections with individual adjustable length, cross section and conductor material
  • 44 x 49 x 22cm (L x H x W)
  • Weight - 40Kg (including case and accessories)
