Omicron CPC 100 Multifunctional Primary Test System

Suitable for a wide range of electrical engineering maintenance, commissioning and installation applications, including;

• Current transformer testing
• Voltage transformer testing
• Power transformer diagnosis
• Power lines testing
• High-voltage (HV) cables
• Grounding systems testing
• Rotating machines testing
• GIS systems testing
• Switchgear and circuit breakers
• IEC 61850 installations and Protection relay testing.

• The Omicron CPC 100 test results can be easily stored on the internal memory and retrieved into a PC using the Ethernet cable connection. Alternatively, storing tests on the USB memory card provided and retrieving them to the laptop provided is also possible.
• To reduce setup times on the substation, the device software allows technicians to set up tests off-site on a PC and later retrieve them to be performed on-site. The tests are automatically saved to optimise time taken, saving data manually.

• Weight: 29 Kg
• Dimensions: 468 x 394 x 233 mm
• Capacity: 800 A (or 2000 A with current booster)
• Frequency range: 15 Hz to 400 Hz

Datasheet

User Guide
